Introduction
The platform, National Virtual Library of India (NVLI) envision to bring together several archival and other electronic resources held with public libraries, museums, Central and State Governments, private collections, etc., on to a single knowledge hub interface. All software programs developed and modified for this project were released in public domain under a GPL license in drupal.org and other repositories such as Github. Being a company specialising in Drupal development services, Zyxware joined hands to compliment IIT-B’s efforts in the solution architecture, design, development, and delivery in this mission of national importance.
Zyxware Technologies developed a series of projects in partnership with NVLI (National Virtual Library of India) and IIT-Bombay (Indian Institute of Technology Bombay). The major ones are given below:
1. Biolog Drupal Distribution
Biolog is Drupal distribution developed and maintained by Zyxware Technologies to build biography portals of eminent leaders in Drupal 8.
Web URL: https://www.drupal.org/project/biolog Year: 2016Sardar Patel Web Portal: http://sardarpatel.nvli.in/
Sardar Patel Web Portal is the first website developed using the Biolog Drupal Distribution. The website is a comprehensive study in the life of Sardar Vallabhai Patel, a key figure in the Indian freedom struggle.
Built on Drupal 8, the website has the ability to translate to different languages. It showcases information about Sardar Patel collected from various libraries. A timeline in the site along with interesting titbits, quotes and a quiz tells us who the man is and how he came to be known as the ‘Iron Man of India.’ The digital assets of over 2000 content records can also be viewed based on the theme or main events in his life.
Web URL: http://sardarpatel.nvli.in/
Broad user epic(s) :
Design and develop a web portal that showcases archival records (over 1000 images, 800 documents, several audio and video recordings) about Sardar Patel collected from various libraries
Search tool to locate archival records
Arrange the content in sections such as Biography, Thematic Collections or Timelines.
Should have ability to translate it to different languages in future
Define and implement the data flows, standards, technologies and architecture that will underpin the solution
Why Drupal was chosen:
Drupal was chosen due to the content rich nature of the site, the security associated with rich content workflow along with its ability to translate to multiple languages.
Architecture solution and delivery methodology adopted:
Platform and tools: Drupal 8
Modules Used:
Why these modules/theme/distribution were chosen:
Contributed modules
AudioField
Adds audio widget for uploading and playing audio files
Blazy
Provides basic Blazy integration for lazy loading and multi-serving images
CAPTCHA
Provides the CAPTCHA API for adding challenges to arbitrary forms
Dropzonejs
Embed
Provides a framework for different types of embeds in text editors
Entity
Provides expanded entity APIs
Entity Browser
Provides a generic entity browser/picker/selector
Entity Embed
Allows entities to be embedded using a text editor
Entityqueue
Allows users to collect entities in arbitrarily ordered lists
Entity Reference Revisions
Adds Entity Reference field type with revision support
Facets
Faceted search interfaces that can be used on Search API searchers
Field collection
Provides a field collection field, to which any number of fields can be attached
File Browser
Provides a default Entity Browser for files, using Masonry and Imagesloaded
Language Switcher Dropdown
Provides a dropdown select to switch between available languages
Media entity
Media entity API
Media entity audio
Media entity for audio files
Media Entity Browser
This module provides an Entity Browser for Media Entity
Media entity document
Media entity local documents provider
Media entity image
Media entity local images provider
Paragraphs
Enables the creation of paragraphs entities
reCAPTCHA
Protects your website from spam and abuse while letting real people pass through with ease
Search API
Provides a generic framework for modules offering search capabilities
Search API attachments
Extract and index file fields content
Solr search
Offers an implementation of the Search API that uses an Apache Solr server for indexing content
Slick
Slick carousel, the last carousel you'll ever need
Slick Media
Provides Slick carousel integration with Media entity
Slick Views
Provides Slick carousel integration with Views
SMTP Authentication Support
Allow for site emails to be sent through an SMTP server of your choice
Translation Management Core
Core functionality for the Translation Management Suite
Video.js Player
Video.js is an HTML5 Video Player
ViewerJS
Inspired to gmail's attachment preview, using Viewerjs.org library
Third Party Integration: Apache SolrDevelopment Infrastructure: LAMP stack (Linux, Apache, MySQL and PHP)Development Model: Waterfall Methodology
Duration (calendar months) of the project : 3 Months
Approximate person months in the project:
Project Manager
.5 Months
UI/UX Designer
.5 Months
Technical Architect
.5 Months
Developer
3 Months
Tester
1 Months
Summary of Deliverables:
Responsive Theme :
The site was custom designed and built from scratch taking into consideration the requirement specifications of the client. The site being in Drupal 8 was designed to be responsive and user friendly.
Content Migration:
A key part of the project was migrating the 1 TB of data which included videos, images and textual information to be added as content for the site while keeping the site workflow simple and easy to navigate.
We have experience in using the migrate module extensively for multiple projects. In this project we used migrate module to import data that is available in a disk. There was around 1TB of data, including images and PDF documents. We used the Drupal migrate system to import that to the Drupal 8 system we have developed. We have implemented Drush scripts and queue system to do the migration automatically.
Digital Asset Management :
To provide users with easily accessible information, the content on the site is sorted and arranged by the main events or themes as well as the chronological order of events based on the timeline of Sardar Vallabhai Patel.
Custom Search :
Being able to search on a given topic or name was also a requirement, as this site was part of National Virtual Library of India(NVLI).
Watermarking media filesMake Eminent portal as a Drupal distribution:
Biolog is the Drupal distribution developed and maintained by Zyxware Technologies to build biography portals in Drupal 8 (https://www.drupal.org/project/biolog).
Features:
Media Entity
Document
Audio<
Video
RECAPTCHA
Apache Solr
Facets
Google Analytics tracking
Paragraph support
Multilingual support
Media bulk migrate from CSV
Inline PDF viewer
Translation management workflow
2. Mirador Drupal Module
Zyxware Technologies developed a module to integrate Mirador with Drupal for the NVLI (National Virtual Library of India) project.
Mirador is a multi-repository, configurable, extensible, and easy-to-integrate viewer and annotation creation and comparison environment for IIIF resources, ranging from deep-zooming artwork, to complex manuscript objects. It provides a tiling windowed environment for comparing multiple image-based resources, synchronised structural and visual navigation of content using openSeadragon, Open Annotation compliant annotation creation and viewing on deep-zoomable canvases, metadata display, bookreading, and bookmarking.
Web URL: https://www.drupal.org/project/miradorYear: 2016Broad user epic(s) :
The Mirador module:
Works as a Field Formatter in entities.
Provides annotation capabilities in the images.
Mirador module provides a image field formatter and a text field formatter named as mirador.
You can set the field formatter in the "Manage display" of your entity. Eg: /admin/structure/types/manage/article/display.
In the field formatter a setting option is available to map the field values. These field values will be used to generate the metadata of the mirador viewer.
The Mirador plugin:
Mirador implements the full client functionality of the IIIF Image and Presentation APIs.
It provides tools for bringing in metadata, images, structures, and can create, edit, delete, and view annotations in Open Annotation Format.
Appearance is controlled through CSS so it can be restyled.
Mobile friendly.
Why Drupal was chosen:
Drupal was chosen due to the content rich nature of the site, the security associated with rich content workflow along with its ability to translate to multiple languages. The main project was planned to be built predominantly on Drupal 8, Bigpipe, CDN, and RESTful architecture that is elastically scalable.
Architecture solution and delivery methodology adopted :
Platform and tools: Drupal 8
Development Model: Agile Methodology
Project Management System: JIRA
Duration (calendar months) of the project : 1 Month
Approximate person months in the project:
Project Manager
.5 Months
Developer
2 Months
Tester
.5 Months
Summary of Deliverables:
The Mirador Drupal module:
Works as a Image Formatter in entities.
Working:
Image Field Formatter:
Set the field formatter as mirador for the image field, for the entity type you wish to display mirador viewer. This setting will be available in the "Manage Display" of the fields for that entity type.
Set the field mapping for the metadata in the settings form near to the "Format" option.
Once a entity against this entity type is viewed, the mirador-load.js will initiate, a manifest file will be generated by the system, with the provided image and metadata. This manifest file will be passed to mirador.js, The image then will then be loaded via IIIF server provided in the configuration.
These images will be cached by the IIIF Server. The cache directory location can be specified in the IIIF Server configuration.
Text Field Formatter
Set the field formatter as mirador for the text field, for the entity type you wish to display mirador viewer. This setting will be available in the "Manage Display" of the fields for that entity type.
Set the field mapping for the metadata in the settings form near to the "Format" option.
On creating the entity against this entity type, specify the image path in the mirador field. the image path, should be the path from that is set in IIIF Server.
On viewing the entity, The mirador-load.js will initiate, a manifest file will be generated by the system, with the provided image and metadata. This manifest file will be passed to mirador.js, The image then will be loaded via IIIF server provided in the configuration.
These images will be cached by the IIIF Server. The cache directory location can be specified in the IIIF Server configuration.
Annotation
Custom End Point
Go to /admin/config/media/mirador
Set the Annotation Endpoint as "Custom End Point"
Create Endpoint a. Set the endpoint url. b. Set the Create Method. c. For create endpoint, Mirador provides the following data in request object. i. uri -> The resource uri. That is the uri of the image entity, which is being annotated. ii. text -> The annotation text. iii. data -> The annotation data in json format. iv. media -> The media type. In this case image. d. The create endpoint expects the complete created entity back as json response. With id in the entity.
Update/Delete Endpoint a. Set the endpoint url. b. Use token {annotation_id}, for specifying the annotation ID, in url. Mirador will replace it with annotation id. b. Set the update method. c. For update endpoint, Mirador provides the following data in request object. i. uri -> The resource uri. That is the uri of the image entity, which is being annotated. ii. text -> The annotation text. iii. data -> The annotation data in json format. iv. media -> The media type. In this case image. d. The delete endpoint provides nothing the id in request object. e. The update/delete endpoint expects nothing back as response.
Set the permission "Perform annotation operation". This will disable the annotate buttons in the viewer for those without permission to annotate.
REST Endpoint.
Create a entity type to store the annotation data.
Create necessary fields in the entity type to store the annotation data.
Enable "rest" module available in core.
/admin/config/media/mirador enable "Rest endpoint".
Add the entity type data in settings available at /admin/config/media/mirador.
Add field mappings, so that system knows where all to store the data in the provided entity type.
Add proper permissions for content creation/update/view/delete of the created entity type
Add proper permissions for REST Webservice.
Set the permission "Perform annotation operation". This will disable the annotate buttons in the viewer for those without permission to annotate.
The Mirador Viewer:
Open-source, Web based, multi-window image viewing platform with the ability to zoom, display, compare and annotate images from around the world. See project home : http://projectmirador.org/
Installation:
Install the module as normal, see link for instructions.
Download compiled Mirador javascript library into Drupal's libraries directory, usually in`/libraries`. Verify the file permission is web servable. Make sure the path to the plugin is libraries/mirador/mirador.js (Mirador JS library uses jQuery 1.9.1 which is conflicting with Drupal. So we have uploaded a version of mirador at https://github.com/NVLI/mirador-js-drupal) We cannot distribute Mirador Javascript library along with the Drupal module due to incompatibility with GPL v2 and Apache 2 licenses.
Set the IIIF image server in path /admin/config/media/mirador. In the image server specify the path upto files directory, in simple resolver config.
